| Primary Power | DC 12V at3A-24V at1.5A, Power Max. 10W |
| PoE | Supported IEEE802.3at/af compliant, Power Max.12W |
| Operating Frequency/ Standards | - 13.56MHz: ISO14443 types A&B, ISO 15693
- 2.4GHz Bluetooth
|
| RS-485 connection | RS-485 standard/ OSDP V2.0/ 2.2 |
| CPU | 1.2GHz Quad Core ARM Processor |
| NPU | 2.4 TOPs NPU |
| Memory | 1GB RAM+ 8GB Flash |
| Camera | Face Automatic Exposure- Palm Automatic Exposure
- Face Tracking
- Palm Detection
- WDR
- 50Hz/ 60Hz Anti-Flicker
- Dual Camera
- Output image 720x1280 pixels
|
| Ethernet Network Connection | Ethernet: 10 Base-T/ 100 Base-TX, Auto MDI/ MDIX |
| Data Protection | - Complies with TLS 1.2 for end-to-end secure communication channel (Secured Communication between Standalone Terminal and Server)
- AES128 (Secured Communication between the Standalone Terminal and OSDP Readers and Access Control Panels)
|
| Number of Ports | - 1xTCP/ IP
- 1xRS-485
- 4ch TTL Inputs
- 1ch TTL Output
- 2 relays
|
| Inputs | Wiegand, Button, Sensor, Aux Inputs |
| Outputs | Wiegand, Lock Relay, Alarm Relay (Relay via dry contacts) |
| Normally Open Contact Rating | 5A at30Vdc resistive |
| Tamper Switch | Magnetic tamper detection system |
| On-Board Monitor | Size: 5.0", Resolution: 720x1280 |
| Audio Indicator | Internal speaker with adjustable intensity (Configurable on UI) |
| MIC | Supported |
| Video Phone | Support Standard SIP V2.0 |
| User Capacity | 100,000 |
| RFID Card Capacity | 100,000 |
| Maximum RFID Card Number Length | Wiegand In and Out (up to 64 bits) |
| Face Capacity | 50,000 (1:N) / 100,000 (1:1) |
| Palm Capacity | 5,000 (1:N) / 100,000 (1:1) |
| RFID Reading Distance | 13.56MHz and 125KHz: Up to 1.96"/ 50 mm (depending on environment and transponder) |
| Face Authentication Distance | 15.7" - 55.1" (40cm - 140cm) |
| Face Authentication Posture Adaptability | Yaw ≤ 30°, Pitch ≤ 30°, Roll ≤45° |
| Face Authentication Accuracy | True Accept Rate (TAR) =99%, False Accept Rate (FAR) =0.01% |
| Face Authentication Mode | 1:1, 1:N |
| Face Authentication Speed | < 100ms (Field Test Result) |
| Face Authentication Liveness Detection | Yes (Infrared-visible light mode, Infrared Light Mode) |
| Face Mask Detection | Yes |
| Palm Authentication Distance | 7" - 15.7" (18cm - 40cm) |
| Palm Authentication Posture Adaptability | Yaw ≤ 45°, Pitch ≤ 30°, Roll ≤ 90°, Bend ≤ 30° |
| Palm Authentication Accuracy | True Accept Rate (TAR) =98.7%, False Accept Rate (FAR) =0.01% |
| Palm Authentication Mode | 1:1, 1:N |
| Palm Authentication Speed | < 140ms (Field Test Result) |
| Palm Authentication Liveness Detection | Yes (Infrared Light Mode) |
| Recommend Installation Height | 55" (140cm) (Using the plate with tilt angle) 59" (150cm) (Plate with horizontal angle) |
| Transaction Buffer | Records: 1,000,000 |
| Access Group | 99 |
| On-Board Access Point Control | 1 access point on board |
| On-Board Reader Support | 1 (OSDP over RS-485) or 1 (Wiegand Input) |
| Protection / Resistance | Weather and Dust Proof Protection Rating compliant with IP66 |
